Szczegóły Produktu:
|
Skala: | 0 - 100% o₂ | Dokładność: | ± 2% (pełna skala) |
---|---|---|---|
Zakres temperatury pracy: | 5 - 40 ° C. | Zakres temperatur przechowywania: | - 20 - 60 ° C |
Zakres wilgotności względnej: | 10 - 90% wilgotności względnej | Zakres ciśnienia atmosferycznego: | 811 HPA - 1216 HPA |
Podkreślić: | medical oxygen gas sensor,long life oxygen sensor,electrochemical oxygen sensor biotechnology |
Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology
Product Features:
Applications:
Measuring Range | 0 - 100% |
Accuracy | ±2% (full - scale) |
Operating Temperature Range | 5 - 40°C |
Storage Temperature Range | - 20 - 60°C |
Relative Humidity Range | 10 - 90% RH (non - condensing) |
Atmospheric Pressure Range | 811 hPa - 1216 hPa |
Response Time | 60 ± 5 s |
Initial Output Voltage under Standard Test Conditions | 47.0 - 65.0 mV |
Offset Voltage | ≤ 6.0 mV |
Linearity ((VA - V0)/(V100 - V0)) | 0.21 ± 0.02 |
Characteristics (VH/VA, VL/VA) | 0.91 - 1.09 |
Dimensions | φ28 × 47.3 mm |
Weight | Approximately 24 g |
Life Expectancy | 10 years |
